? 聲學性能Acoustic design:10"Passive loudspeaker,2-way
? 配置Components:HF1×1.4"(44mm)driver,LF1×10"(65mm)
? 頻率響應Frequenty range:50Hz-20KHz(-10dB)
? 額定功率Power rating (RMS/Peak 10ms):300W/1200W
? 靈敏度Sensitivity(1w at 1m):96dB
? 最大聲壓級Maximum SPL1m:120dB;124dB(Peak)
? 標稱阻抗Nominal impedance:8?
? 覆蓋角度Nominal dispersion angle(HxV): 100°×70°
? 連接器Connections:2×Speakon NL4
? 尺寸Dimensions (H×W×D):540mm×300mm×340mm
? 重量Weight:18.5Kg
? 型號 Model:MD112
? 聲學性能 Acoustic design:12"Passive loudspeaker,2-way
? 配置 Components:HF1×1.4"(44mm)driver, LF1×12"(75mm)
? 頻率響應 Frequenty range:50Hz-20KHz(-10dB)
? 額定功率 Power rating (RMS/Peak 10ms):350W/1400W
? 靈敏度 Sensitivity(1w at 1m):97dB
? 最大聲壓級 Maximum SPL1m:122dB(Continuous);126dB(Peak)
? 標稱阻抗 Nominal impedance:8?
? 覆蓋角度 Nominal dispersion angle(HxV): 100°×70°
? 連接器 Connections:2×Speakon NL4
? 尺寸 Dimensions (H×W×D):600mm×360mm×385mm
? 重量 Weight:20.2Kg
